  • I loaded True Nas onto the internal SSD and swapped out the HDD drive that came with it for a 10tb drive.

    Do I understand that you currently have a SATA SSD and a 10TB SATA HDD plugged into this machine?

    If so, it seems like a SATA power splitter that divides the power to the SSD would suffice, in spite of the computer store’s admonition. The reason for splitting power from the SSD is because an SSD draws much less power than spinning rust.

    Can it still go wrong? Yes, but that’s the inherent risk when pushing beyond the design criteria of what this machine was originally built for. That said, “going wrong” typically means “won’t turn on”, not “halt and catch fire”.


  • IMO, circular buffers with two advancing pointers are an awesome data structure for high performance compute. They’re used in virtualized network hardware (see virtio) and minimizing Linux syscalls (see io_uring). Each ring implements a single producer, single consumer queue, so two rings are usually used for bidirectional data transfer.

    It’s kinda obscure because the need for asynchronous-transfer queues doesn’t show up that often unless dealing with hardware or crossing outside of a single CPU. But it’s becoming relevant due to coprocessors (ie small ARM CPUs attached to a main CPU) that process offloaded requests and then quickly return the result when ready.


  • In any case, pending your reply, I would suggest the following circuit for reliable operation. This will require a P-channel MOSFET, which is different from the two MOSFETs you tried earlier, which are all N-channel. This will also use two resistors. I am making an assumption that your speaker module simply requires two wires at feed it 4 volts, and does not care whether we add a switching circuit to either wire, the positive or negative wire.

    suggested circuit 1

    This type of circuit would be described as an inverting, low-side MOSFET switching circuit. The inverting part means that when the MOSFET is fed a lower voltage, that causes the transistor to become active, whereas a non-inverting circuit would require feeding the MOSFET with a higher voltage to make the transistor become active.

    Low-side switching refers to the fact that the load (ie the speaker module) is permanently attached to the higher voltage (the high-side) and we are manipulating the low-side. Not all electronic loads can be used with low-side switching, but this is the easiest mode to implement using a single MOSFET transistor. As a general rule, to do low-side switching always requires a P-channel MOSFET. WARNING: a P-channel MOSFET has its drain/source reversed from how an N-channel MOSFET is usually wired up. Observe the schematic very carefully.

    As for why we cannot do high-side switching (which would use an N-channel MOSFET), it is because a typical N-channel MOSFET requires that the gate be a few volts higher than the source. But consider that when the transistor turns on, the drain and source become almost-similar voltages. So if the drain is attached to 4 volts, and as the transistor becomes active, the source rises to something like 3.95 volts, then what gate do we use to keep the transistor active? If we give 4v to the drain, then the gate-to-source voltage is a mere 0.05 volts, which is insufficient to keep the transistor on. We would need an external source to provide more gate voltage, relative to the source pin. If we tried such a high-side switching circuit anyway, it would quickly oscillate: the transistor tries to turn on, then turns itself off, then back on, and so forth. Or it would sit comfortably at some half-way gate voltage, where the transistor is barely-on, barely-off. This is not useful as a switching circuit.

    The way that my suggested circuit works is as follows: when the tripwire (marked as SW3) is in place, then R4 and R2 will form a voltage divider. Given that the battery supplies 4v, we can show that the voltage at the MOSFET’s gate will be 91% of 4v, or 3.64 volts. This should be just enough to prevent the P-channel MOSFET from becoming active. Note: a P-channel MOSFET becomes active when there is a low gate-to-drain voltage, with 0v causing the transistor to become active. In this way, with the trip-wire, the transistor will not allow current to pass through the speaker.

    When the tripwire is pulled out, this breaks the connection to R4. That leaves the gate connected to only R2, which is connected to the negative side of the battery. Thus, any charge in the gate will seep away through R2, meaning that the voltage across R2 will equalize at 0v. This means the gate-to-drain voltage will be 0v, which means the MOSFET will activate. And that allows current to power the speaker module.

    Note: one end of the tripwire (labeled #1 in the diagram) will still have 4v on it. If the tripwire is cleanly detached from the whole circuit, using your loop-of-wire and nails idea, then there is no problem. But if the tripwire is still hanging onto the 4v side of the circuit, then be careful that the tripwire doesn’t make contact with another part of this circuit. The R4 resistor will still be there, so there won’t be a short circuit or anything bad like that. But if that tripwire reconnects to the gate, then the transistor will deactivate again, stopping the music.

    I wish you good luck in this endeavor!


  • I’m going to try to answer your situation, but although time appears to be of the essence, I need to first understand exactly what you’ve already tried. So bear with me for a moment.

    The examples I found were very simple, involving an NPN transistor (2n2222), 10KΩ resistor, battery, and DC Piezo speaker.

    With my initial attempt, I wired +4V from the switch to the transistor’s collector and then separated the collector from the base with a resistor. I connected the emitter to the pin that, when the switch is engaged, would send 4V through and power the module.

    Does this diagram correctly describe what you tried as a first attempt?

    schematic diagram of attempt 1

    Someone suggested that what I actually needed was a MOSFET …

    I have the resistor connected between Gate and Drain, +4V going to drain, and the load from the module on Source.

    With an RFP30N06LE, I get about 2V output to Source. With an IRF840N, I’m only getting 0.9V.

    Do these diagrams match your circuits with each MOSFET?

    schematic diagram of attempt 2

    schematic diagram of attempt 3

    What I am not able to understand, in your last photo with the MOSFET, is where the blue wire is going.


  • If I understand the Encryption Markdown page, it appears the public/private key are primarily to protect the data at-rest? But then both keys are stored on the server, although protected by the passphrase for the keys.

    So if the protection boils down to the passphrase, what is the point of having the user upload their own keypair? Are the notes ever exported from the instance while still being encrypted by the user’s keypair?

    Also, why PGP? PGP may be readily available, but it’s definitely not an example of user-friendliness, as exemplified by its lack of broad acceptance by non-tech users or non-government users.

    And then, why RSA? Or are other key algorithms supported as well, like ed25519?



  • One way to make this more Pythonic – and less C or POSIX-oriented – is to use the pathlib library for all filesystem operations. For example, while you could open a file in a contextmanager, pathlib makes it really easy to read a file:

    from pathlib import Path
    ...

    config = Path("/some/file/here.conf").read_text()


    This automatically opens the file (which checks for existence), reads out the entire file as a string (rather than bytes, but there’s a method for that too), and then closes up the file. If any of those steps go awry, you get a Python exception and a backtrace explaining exactly what happened.


  • To many of life’s either-or questions, we often struggle when the answer is: yes. That is to say, two things can hold true at the same time: 1) LLMs can result in job redundancies, and 2) LLMs hallucinate results.

    But if we just stopped the analysis there, we wouldn’t have learned anything. To use this reality to terminate any additional critical thinking is, IMO, wholly inappropriate for solving modern challenges, and so we must look into the exact contours of how true these statements are.

    To wit, LLM-induced job redundancies could come from skills which have been displaced by the things LLMs can do well. For example, typists lost their jobs when businesspeople were expected to operate a typewriter on their own. And when word processing software came into existence for the personal computer, a lot of typewriter companies folded or were consolidated. In the case of LLMs, consider that people do use them to proofread letters for spelling and grammar.

    Technologically, we’ve had spell-check software for a while, but grammar was harder. In turn, an industry appeared somewhere in the late 2000s or early 2010s to develop grammar software. Imagine how the software devs at these companies (eg Grammarly) might be in a precarious situation, if an LLM can do the same work. At least with grammar checking, even the best grammar software still struggles with some of the more esoteric English sentence constructions, so if an LLM isn’t 100% perfect, that’s still acceptable. I can absolutely see the fortunes of grammar software companies suffering due to LLMs, and that means those software devs are indeed threatened by what LLMs can do.

    For the second statement, it is trivial to find examples of LLMs hallucinating, sometimes spectacularly or seemingly ironic (although an LLM would be hard-pressed to simulate the intention of irony, I would think). In some fields, such hallucinations are career-limiting moves for the user, such as if an LLM was used to advise on pharmaceutical dosage, or used to draft a bogus legal appeal and the judge is not amused. This is very much a FAFO situation, where somehow the AI/LLM companies are burdened with none of the risk and all of the upside. It’s like how autonomous driving automotive companies are somehow allowed to do public road tests of their beta-quality designs, but the liability for crashes still befalls the poor sod seated behind the wheel. Thoss companies just keep yapping about how those crashes are all “human error” and “an autonomous car is still safer”.

    But I digress.

    My point is that LLMs have quite a lot of capabilities, and people make a serious mistake when they assume its incompetence in one capacity reflects its competency in another. This is not unlike how humans assess other humans, such as how a record-setting F1 driver would probably be a very good chauffeur for a limousine company. But whereas humans have patterns that suggest they might be good (or bad) at something, LLMs are a creature unlike anything else.

    I personally am not bullish on additional LLM improvements, and think the next big push will require additional academic research, being nowhere near commercialization. But even I have to recognize that some very specific tasks are decent using today’s availabile LLMs. I just don’t think that’s good enough for me to consider using them, given their subscription costs, the possibility of becoming dependent, and being too niche.


  • Using an MSP430 microcontroller, I once wrote an assembly routine that (ab)used its SPI peripheral in order to stream a bit pattern from memory out to a GPIO pin, at full CPU clock rate, which would light up a “pixel” – or blacken it – in an analog video signal. This was for a project that superimposed an OSD onto the video feed of a dashcam, so that pertinent vehicle data would be indelibly recorded along with the video. It was for one heck of a university project car.

    To do this, I had to study the MSP430 instruction timings, which revealed that a byte could be loaded from SRAM into the SPI output register, then a counter incremented, then a comparison against a limit value in a tight loop, all within exactly 8 CPU cycles. And the SPI completes an 8-bit transfer every 8 SPI clock cycles, but the CPU and SPI blocks can use the same clock source. In this way, I can prepare a “frame buffer” of bits to write to the screen – plenty of time during the vertical blanking interval of analog video – and then blast it atop the video signal.

    I think I ended up running it at 8 MHz, which gave me sufficient pixel resolution on a 480i analog video signal. Also related was the task of creating a set of typefaces which would be legible on-screen but also be efficient to store in the MSP430’s limited SRAM and EEPROM memories. My job was basically done when someone else was able to use printf() and it actually displayed text over the video.

    This MSP430 did not have a DMA engine, and even if it did, few engines permit an N-to-1 transaction to write directly to the SPI output register. Toggling the GPIO register directly was out of the question, due to taking multiple clock cycles to toggle a single bit and load the next value. Whereas my solution was a sustained 1 bit per clock cycle at 8 MHz. All interrupts disabled too, except for the vertical and horizontal blanking intervals, which basically dictated the “thinking time” available for the CPU.


  • litchralee@sh.itjust.workstoSelfhosted@lemmy.worldPassword managers...
    link
    fedilink
    English
    arrow-up
    5
    arrow-down
    1
    ·
    edit-2
    26 days ago

    For a single password, it is indeed illogical to distribute it to others, in order to prevent it from being stolen and misused.

    That said, the concept of distributing authority amongst others is quite sound. Instead of each owner having the whole secret, they only have a portion of it, and a majority of owners need to agree in order to combine their parts and use the secret. Rather than passwords, it’s typically used for cryptographically signing off on something’s authenticity (eg software updates), where it’s known as threshold signatures:

    Imagine for a moment, instead of having 1 secret key, you have 7 secret keys, of which 4 are required to cooperate in the FROST protocol to produce a signature for a given message. You can replace these numbers with some integer t (instead of 4) out of n (instead of 7).

    This signature is valid for a single public key.

    If fewer than t participants are dishonest, the entire protocol is secure.




  • https://ipv6now.com.au/primers/IPv6Reasons.php

    Basically, Legacy IP (v4) is a dead end. Under the original allocation scheme, it should have ran out in the early 1990s. But the Internet explosion meant TCP/IP(v4) was locked in, and so NAT was introduced to stave off address exhaustion. But that caused huge problems to this day, like mismanagement of firewalls and the need to do port-forwarding. It also broke end-to-end connectivity, which requires additional workarounds like STUN/TURN that continue to plague gamers and video conferencing software.

    And because of that scarcity, it’s become a land grab where rich companies and countries hoard the limited addresses in circulation, creating haves (North America, Europe) and have-nots (Africa, China, India).

    The want for v6 is technical, moral, and even economical: one cannot escape Big Tech or American hegemony while still having to buy IPv4 space on the open market. Czechia and Vietnam are case studies in pushing for all-IPv6, to bolster their domestic technological familiarity and to escape the broad problems with Business As Usual.

    Accordingly, there are now three classes of Internet users: v4-only, dual-v4-and-v6, and v6-only. Surprisingly, v6-only is very common now on mobile networks for countries that never had many v4 addresses. And it’s an interop requirement for all Apple apps to function correctly in a v6-only environment. At a minimum, everyone should have access to dual-stack IP networks, so they can reach services that might be v4-only or v6-only.

    In due course, the unstoppable march of time will leave v4-only users in the past.


  • You might also try asking on !ipv6@lemmy.world .

    Be advised that even if a VPN offers IPv6, they may not necessarily offer it sensibly. For example, some might only give you a single address (aka a routed /128). That might work for basic web fetching but it’s wholly inadequate if you wanted the VPN to also give addresses to any VMs, or if you want each outbound connection to use a unique IP. And that’s a fair ask, because a normal v6 network can usually do that, even though a typical Legacy IP network can’t.

    Some VPNs will offer you a /64 subnet, but their software might not check if your SLAAC-assigned address is leaking your physical MAC address. Your OS should have privacy-extensions enabled to prevent this, but good VPN software should explicitly check for that. Not all software does.


  • Connection tracking might not be totally necessary for a reverse proxy mode, but it’s worth discussing what happens if connection tracking is disabled or if the known-connections table runs out of room. For a well-behaved protocol like HTTP(S) that has a fixed inbound port (eg 80 or 443) and uses TCP, tracking a connection means being aware of the TCP connection state, which the destination OS already has to do. But since a reverse proxy terminates a TCP connection, then the effort for connection tracking is minimal.

    For a poorly-behaved protocol like FTP – which receives initial packets in a fixed inbound port but then spawns a separate port for outbound packers – the effort of connection tracking means setting up the firewall to allow ongoing (ie established) traffic to pass in.

    But these are the happy cases. In the event of a network issue that affects an HTTP payload sent from your reverse proxy toward the requesting client, a mid-way router will send back to your machine an ICMP packet describing the problem. If your firewall is not configured to let all ICMP packets through, then the only way in would be if conntrack looks up the connection details from its table and allows the ICMP packet in, as “related” traffic. This is not dissimilar to the FTP case above, but rather than a different port number, it’s an entirely different protocol.

    And then there’s UDP tracking, which is relevant to QUIC. For hosting a service, UDP is connectionless and so for any inbound packet we received on port XYZ, conntrack will permit an outbound packet on port XYZ. But that’s redundant since we presumably had to explicitly allow inbound port XYZ to expose the service. But in the opposite case, where we want to access UDP resources on the network, then an outbound packet to port ABC means conntrack will keep an entry to permit an inbound packet on port ABC. If you are doing lots of DNS lookups (typically using UDP), then that alone could swamp the con track table: https://kb.isc.org/docs/aa-01183

    It may behoove you to first look at what’s filling conntrack’s table, before looking to disable it outright. It may be possible to specifically skip connection tracking for anything already explicitly permitted through the firewall (eg 80/443). Or if the issue is due to numerous DNS resolution requests from trying to look up spam sources IPs, then perhaps either the logs should not do a synchronous DNS lookup, or you can also skip connection tracking for DNS.


  • https://github.com/Overv/vramfs

    Oh, it’s a user space (FUSE) driver. I was rather hoping it was an out-of-tree Linux kernel driver, since using FUSE will: 1) always pass back to userspace, which costs performance, and 2) destroys any possibility of DMA-enabled memory operations (DPDK is a possible exception). I suppose if the only objective was to store files in VRAM, this does technically meet that, but it’s leaving quite a lot on the table, IMO.

    If this were a kernel module, the filesystem performance would presumably improve, limited by how the VRAM is exposed by OpenCL (ie very fast if it’s just all mapped into PCIe). And if it was basically offering VRAM as PCIe memory, then this potentially means the VRAM can be used for certain RAM niche cases, like hugepages: some applications need large quantities of memory, plus a guarantee that it won’t be evicted from RAM, and whose physical addresses can be resolved from userspace (eg DPDK, high-performance compute). If such a driver could offer special hugepages which are backed by VRAM, then those application could benefit.

    And at that point, on systems where the PCIe address space is unified with the system address space (eg x86), then it’s entirely plausible to use VRAM as if it were hot-insertable memory, because both RAM and VRAM would occupy known regions within the system memory address space, and the existing MMU would control which processes can access what parts of PCIe-mapped-VRAM.

    Is it worth re-engineering the Linux kernel memory subsystem to support RAM over PCIe? Uh, who knows. Though I’ve always like the thought of DDR on PCIe cards. All technologies are doomed to reinvent PCIe, I think, said someone from Level1Techs.



  • For my own networks, I’ve been using IPv6 subnets for years now, and have NAT64 translation for when they need to access Legacy IP (aka IPv4) resources on the public Internet.

    Between your two options, I’m more inclined to recommend the second solution, because although it requires renumbering existing containers to the new subnet, you would still have one subnet for all your containers, but it’s bigger now. Whereas the first solution would either: A) preclude containers on the first bridge from directly talking to containers on the second bridge, or B) you would have to enable some sort of awful NAT44 translation to make the two work together.

    So if IPv6 and its massive, essentially-unlimited ULA subnets are not an option, then I’d still go with the second solution, which is a bigger-but-still-singular subnet.


  • I see. Given those constraints then, I don’t see any option besides a new heater. Ideally, the new heater would be built with less circuitry, so there would be fewer things to break.

    Looking at the Adax Clea product description, it seems overly complicated for a radiator, IMO. I’m not sure I’d want triac switching for something like a heating appliance. Resistive heating doesn’t strictly require silicon switches, when a relay should work. But I suspect an equally-svelt radiator that’s also simple may be hard to find.
